MINALOX RAIL SYSTEM M-series 1m Black Loxone dimmable

The MINALOX MAGNETIC RAIL SYSTEM M410/BK forms the foundation of the rail lighting in the DUALWHITE version. All lamps from the MINALOX TRACKLIGHT series can be used in the rail.

Key features:

• Mounting options: Designed for both surface-mounted and pendant installation (when using M195 or M191).
• Finish: Matte black powder coating for an elegant look, perfect for modern interiors.
• Power supply: Operates on 24V DC and is compatible with smart systems, making integration into smart homes or professional spaces simple.

Durable and flexible design:

• Housing: Made of aluminum with compact dimensions (26.6 × 26.6 mm), ensuring high durability and long lifespan.
• Unobtrusive: The subtle design does not disrupt the overall architectural concept.
• Modular system: Strips can be shortened and connected, depending on the space's needs, for maximum lighting variation.

Easy installation and compatibility:

• Installation: Quick and easy installation of compatible MINALOX TRACKLIGHT luminaires without special tools.
• Compatibility: Supports the DUALWHITE version and is ready for integration with systems like LOXONE, TapHome, Ampio, KNX, and other PWM solutions.

Adaptability:

• Connectors and accessories: Extensive system available to create various shapes, from simple lines to complex circuit solutions.
• Power sections: Ability to divide the strip into separate power sections, allowing multiple independent light circuits within one form. For example, in a rectangular setup, each arm can have its own control.

Specifications:

• Length: 1000 mm
• Recommended maximum strip length: 3000 mm (single power point)
• Color: Black (RAL 9005, matte black)
• Compatibility: LOXONE, TapHome, Ampio, KNX, other systems with PWM control
• Compatible lamps: MINALOX TRACKLIGHT series
• Material: Aluminum
• Maximum current/power: 10A / 240W (at 24V DC)
• Mounting: Ceiling or wall
• Power voltage: 24V DC
• Modularity: Can be shortened and combined
• Protection level: IP20
• Dimensions: Width 26.6 mm, Height 26.6 mm
• Warranty: 5 years

With the MINALOX MAGNETIC RAIL SYSTEM, you choose a versatile, elegant, and durable lighting solution.
