MINALOX LED SPIKE MUSHROOM 300 D136 DualWhite 20W 24V 1800-4500K Black

Specifications

• Chromaticity (CCT): 1883K / 4801K / 3050K
• Color: black
• Frequency range: 100Hz - 20kHz
• Color rendering index CRI (Ra): 92.5 / 96.3 / 92
• Compatibility: LOXONE, TapHome, Ampio, KNX, other systems with PWM control
• Material: Aluminum + PMMA lens
• Power supply voltage: 24V DC
• Luminaire optics: PMMA diffuser
• Surface treatment: Powder coating, RAL 9005 (fine structure, black)
• Operating temperature: -20°C - 50°C
• Design: DUALWHITE
• Diameter (mm): 138
• Power consumption (W): 10.42 / 10.34 / 20.78
• Connection: 3-core
• Control: PWM dimming (0–100%)
• Protection level: IP67
• Luminous efficacy (lm/W): 40.5 / 61.2 / 50
• Luminous flux (lm): 422 / 633 / 1040
• Type: Approximate
• Lighting angle: Asymmetric
• Execution: Recessed, exterior
• Height (mm): 333
• Warranty: 5 years
• Lifetime (hours): 50,000
